Especificaciones técnicas

• Interfaz
• 24 x 10/100/1000BASE-T
• 4 x 100/1000Mbps combo
• Estándar
• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)
• IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.3x Flow Control
• Cables Red

• UTP Cat. 5, Cat. 5e (100 m max.)

• Duplex Mode

• Full/Half-duplex for 10/100 Mbps

• Full-duplex for 1000 Mbps

• Interfaz Media Intercambio

• Ajuste automático MDI/MDIX para todos los puertos de par trenzado

• Ahorro de energía
• Link Status detection
• LED Shut-Off
• Port Shut-Off
• System Hibernation
• Time-based PoE (DGS-1210-10P/28P/52P/52MP only)

• Seguridad

• Access Control List secures network
• D-Link Safeguard Engine protects CPU from Broadcast/Multicast/Unicast Flooding
• Port Security supports 64 MACs per port
• ARP Spoofing Prevention

• Intuitive Management

• D-Link Network Assistant Utility or Web-based GUI
• Built-in SNMP MIB for remote NMS (D-View 6.0)
• Compact CLI through Telnet

• Prestaciones avanzadas

• Auto Surveillance VLAN
• Loopback Detection automatically disables a port when a loop is detected
• Cable Diagnostics allows administrators to determine cable status
• SFP ports for flexibility
• Auto MDI/MDIX

• Interface

• Puertos 10/100/1000BASE-TX
• DGS-1210-28 - 24 puertos
• Puertos SFP
• DGS-1210-28 - 4 puertos

• Rendimiento

• Switch Capacity
• DGS-1210-28- 56 Gbps
• 64-Byte Packet Forwarding Rate
• DGS-1210-28 - 41.7 Mpps
• MAC Address Table Size
• 16K
• Packet Buffer
• DGS-1210-10/20/28- 1.5 MB per device

• Consumo (Standby/Maximum)

• DGS-1210-28 - 17.84W / 22.45W

• Power Input

• 10 to 240 VAC, 50/60HZ

• Dimensiones (W x D x H)

• DGS-1210-28 - 440 x 140 x 44 mm

• Peso

• DGS-1210-28 - 1.67 kg

• Certificaciones

• CE Class A, VCCI Class A, FCC Class A, cUL, CE (LVD), BSMI, CCC, C-Tick
